Page 56 - Rescue Source Catalog

2020
2021
54
CMC ANCHOR PLATE UL Classified to NFPA 1983 General Use
PETZL PAW RIGGING PLATE
UL Classified to NFPA 1983 General Use
RQ3 STRETCHER RIGGING PLATE
Features include:
Keeps the carabiners holding the different parts of your rescue system from jamming together
Can also keep you from clipping a cara- biner into the wrong loop of the anchor webbing
Weight: 7.4 oz.
Material: Stainless steel
Strength: 9,666 lbf. (43kN)
Features include:
Designed as a connection point with enough holes for all lines
Used for litter points, litter tender, or complex systems
Weight: 11.84 oz.
Material: Aluminum
Strength: 12,200 lbf (54kN)
Dimensions: 10” x 3.75”
Features include:
Designed for easily organizing work stations and creating multi-anchor systems
Weight: 7.4 oz.
Material: Aluminum
Strength: 8,093 lbf. (36 kN)
Hole diameter: 9mm
Item# PR5950N | $80.00
Item# PR5980 | $69.50 ROCK EXOTICA OMNI BLOCK PULLEY
Item# PR6025 | $54.95 CE Certified to UIAA127 /EN12278
The Omni Block pulley makes some very basic but effective changes to the rescue pulley. First, by adding a swivel to the top of the body, the Omni allows the pulley to ro- tate with the rope, reducing friction and equipment failures brought on by torque in a system. The swivel also acts as the pulley’s attachment point to the system, allow- ng rescuers to rig and re-rig pulleys at will without needing to manipulate carabiners.
i
ITEM #
TYPE
MBS
WEIGHT
PRICE
PU5100
Single
ROCK EXOTICA KOOTENAY ULTRA PULLEY CE Certified to UIAA127 /EN12278
The Kootenay Ultra knot-passing pulley has two holes for tag lines, a dual bearing and other features make the Kootenay Ultra the most advanced pulley of its type. Extremely compact and lightweight. Simplifies high-strength tie-off with a single locking screw, stowable within the axle. Uses two inde- pendent sealed ball bearings for increased durability and efficiency. Two additional holes to sepa- rate tag lines and hoist lines, helping prevent spinning of the load and interference with connectors.
8,093 lbf. (36kN)
9.2 oz
$94.00
PU5150
Double w/Becket
8,093 lbf. (36kN)
14.5 oz
$138.00
ITEM #
TYPE
SHEAVES
DIMENSIONS
MBS
WEIGHT
PRICE
PU5125
Double bearing
2.2”
8.57” x 4.1” x 2.94”
8,767 lbf. (39kN)
25 oz
$225.00
1-800-457-3728
HARDWARE
