Page 53 - Rescue Source Catalog
P. 53
CMC MPDTM Multi-purpose Device
UL Classified to NFPA 1983 General Use
CMC CLUTCHTM BY HARKEN INDUSTRIALTM
Work/Rescue Descender
UL Classified to NFPA 1983 (2017 ED) General Use; ANSI/ASSE Z359.4-2013; EN 12841: 2006/C; EN 341: 2011/2A; EN 15151-1: 2012/8
Features include:
A high-efficiency pulley with an integr rope-locking mechanism (ratchet) for haul system
al a
Built-in becket allows cleaner rigging a efficient pulley systems
MBS: 11,015 lbf. (49kN)
Weight: 2.6 lbs.
Item# AS3300 | $799.00
PMI D5
Work/Rescue Descender
UL Classified to NFPA 1983/2017 General Use EN12841:2006/C, ANSI Z359.4:2013
Item# AS3500 | $649.00 PETZL I’D®
Self-Braking Descender
UL Classified to NFPA 1983 Technical Use
CE EN 241 Class A, CE EN 12841 type C,
ANSI Z359.4, EAC, EN 341 Class A, CE EN 15151-1
nd
Features include:
Single, wearable tool suited for efficient hauling, controlled lowering, smooth personal descent, easy ascending and belaying
Allows main line and belay line rigging to be mirrored or twin- tensioned
Stainless steel ratcheting and rotating sheave provides ef- ficient and audible progress capture
Functions as a lowering brake device and as a ratcheting pul- ley for raising
Rope loading/unloading is secured with an innovative double- latched side plate design that is independent of the device's attachment point
Ideal for confined space operations because it converts rap- idly to a retrieval line
Anti-Panic brake and force limiting features ensure operational safety and overload protection
Rope compatibility: 12.5 - 13 mm
(11mm design available by special order UL rated "T" Technical Use)
Integrated becket allows for direct connection of mechanical advantage systems
Rope size: 10.5 - 11.5 mm (7/16 in.)
MBS: Pulley 8,992 lbf. (40kN) / Becket 4,496 lbf. (22kN)
Max load: 600 lbs. (272 kg)
Weight: 1.84 lbs. (836 g)
Features include:
Features include:
Double-stop device with an auto-lock function, which is activated whenever the operator releases the handle; and a panic-brake function
With anti-panic function, the I'D self-braking de- scender is primarily designed for technical rescue
Has a double-locking safety mechanism
It has an ergonomic handle that allows convenient descent control
The integrated anti-panic function and anti-error catch limit the risk of an accident due to user error
The side plates are designed so that they cannot be rotated open while under load, due to the position of the carabiner
The auto-lock system allows users to position themselves without having to manipulate the handle or tie off the device
Easy to attach/detach from the rope without having to detach from the harness
Features a progressive cam action, which offers precise control during low or high speeds
Once locked, the rope can be taken up without having to manipulate the handle
The safety gate allows the rope to be installed with the device remaining connected to the harness
The cam is made from solid, stainless steel for maximum durabil- ity, even in harsh environments, such as Geotech work
Rope size: 12.5 mm - 13 mm
Weight: 1.31 lbs.
WLL (working load limit): 600 lbs.
MBS: 4,945 lbf. (22kN)
Weight: 1.81 lbs.
2020
2021
WLL (working load limit): 500 lbs.
Item# AS2510 | $278.75
Item# AS4000NL
11.5-13mm rope | $299.95
Item# AS4000NS
10-11.5mm rope | $299.95
HARDWARE
rescuesource.com
51
