   STOCKED BRAND BY RESCUE SOURCE
UL Classified to NFPA 1983 General Use, EN 1891 A | Ansi Z133
KM III static kernmantle rope is an exceptional static rope for rappelling, caving, rescue, top roping, fixed rope applications, hauling and life-safety applications. The unique polyester sheath differentiates KM III from other static ropes. The polyester sheath is balanced with a nylon core to limit rotation, bouncing, and stretch. Ropelab tests demonstrated polyester sheaths significantly outperformed nylon in abrasion tests. Each piece of KM III rope comes with an NFPA certification tag and CE labels. Thirty-two bobbins provide the correct sheath for the unique demands of static rope and the optimum sheath/core ratio. This allows for an incredibly smooth sheath, higher tensile strengths, and superior handling characteristics.
Features:
• Polyester over nylon with a balanced torque free construction • Excellent handling and knot holding characteristics
• High abrasion resistance
• Excellent UV protection
The following specifications apply to all diameters of KM III:
• Construction: Block creel, low-stretch (static) kernmantle construction • Fiber: The core is 100% nylon and the sheath is 100% polyester
• Sheath: Braided polyester jacket, 32 carrier, two over two under
construction with half of the strands having a Z-twist and half having an S-twist • Strength: 7/16”- 7,900 lbs. (35kN) 1/2” - 10,350 lbs. (46kN)
• Elongation: 7/16”- 3.51% at 450 lbs. 1/2”- 3% at 450 lbs.
• Temperature: Melt point 480OF (248OC)
 NFPA GENERAL USE LIFELINE
     LENGTH
  WHITE
  RED | ORANGE | GREEN
   RP5065
1/2” (13mm) diameter
    150’ (46m)
  $200.55
  $228.90
 200’ (61m)
  $265.65
  $303.45
 300’ (92m)
  $403.20
  $457.80
 600’ (183m)
   $760.20
   $877.80
    NFPA TECHNICAL USE LIFELINE
Other colors available by special order:
Black, Blue, OD Green
 ITEM #
  DIAMETER
  LENGTH
  WHITE
  RED | ORANGE | GREEN
   RP5075
7/16” (11mm) diameter
    150’ (46m)
  $172.20
  $200.55
 200’ (61m)
  $224.70
  $265.65
 300’ (92m)
  $347.55
  $391.65
 600’ (183m)
   $638.40
   $715.05
   We can special order New England Ropes' full line.
